Available Many Sizes :
| D | d | g | h1 | e | f | h | L1 | L2 | L3 | L4 | H | D1 | M |
| ø30 | 46 | 50 | 84 | 64 | 99 | 104 | ≤640 | 199 | 270 | 435 | 77 | 85 | M45 |
| ø32 | 50 | 53 | 89 | 68 | 105 | 112 | ≤680 | 211 | 280 | 456 | 83 | 92 | M48 |
| ø34 | 52 | 57 | 95 | 74 | 112 | 116 | ≤708 | 224 | 289 | 472 | 84 | 98 | M52 |
| ø36 | 56 | 60 | 100 | 76 | 115 | 124 | ≤739 | 233 | 300 | 493 | 93 | 105 | M56 |
| ø38 | 60 | 63 | 106 | 81 | 118 | 132 | ≤768 | 242 | 310 | 509 | 93 | 105 | M56 |
| ø40 | 62 | 65 | 111 | 85 | 132 | 138 | ≤802 | 262 | 320 | 530 | 99 | 110 | M60x4 |
| ø42 | 66 | 70 | 117 | 88 | 138 | 145 | ≤832 | 274 | 325 | 541 | 99 | 110 | M60x4 |
| ø45 | 70 | 75 | 125 | 95 | 148 | 155 | ≤890 | 293 | 338 | 562 | 101 | 115 | M64 |
| ø48 | 74 | 80 | 132 | 100 | 156 | 165 | ≤939 | 316 | 350 | 595 | 105 | 120 | M68 |
| ø52 | 80 | 85 | 144 | 108 | 170 | 178 | ≤1014 | 342 | 380 | 647 | 120 | 125 | M72x6 |
| ø56 | 88 | 93 | 154 | 117 | 185 | 192 | ≤1078 | 369 | 400 | 684 | 127 | 140 | M80x6 |
| ø60 | 94 | 100 | 166 | 126 | 196 | 206 | ≤1142 | 392 | 417 | 716 | 130 | 145 | M85x6 |
| ø65 | 102 | 108 | 180 | 136 | 214 | 222 | ≤1225 | 425 | 436 | 756 | 136 | 160 | M90x6 |
| ø70 | 108 | 117 | 194 | 147 | 230 | 240 | ≤1301 | 456 | 465 | 806 | 144 | 175 | Tr100X6 |
| ø75 | 116 | 125 | 208 | 158 | 246 | 258 | ≤1370 | 491 | 485 | 855 | 164 | 180 | Tr105x6 |
| ø80 | 124 | 133 | 222 | 167 | 263 | 275 | ≤1418 | 523 | 490 | 880 | 159 | 185 | Tr110x6 |
| ø85 | 132 | 141 | 236 | 177 | 280 | 292 | ≤1485 | 555 | 500 | 910 | 176 | 200 | Tr115x6 |
| ø90 | 140 | 150 | 250 | 190 | 296 | 310 | ≤1533 | 586 | 515 | 945 | 181 | 210 | Tr120X6 |
| ø95 | 148 | 159 | 263 | 200 | 312 | 327 | ≤1598 | 617 | 525 | 980 | 191 | 220 | Tr130x6 |
| ø100 | 156 | 167 | 278 | 210 | 328 | 344 | ≤1657 | 648 | 530 | 1005 | 198 | 230 | Tr135x6 |
